LINE A-04
SHIFT 2
BATCH B-2291
--:--:-- UTC● LIVE (simulated feed)
Upload image
demo model
Inspection queue
5 items
INSPECTION #88213· Steel bracket SB-140
Defective
STRUCTURAL CRACK · 0.4 mm
X 451 · Y 218 · 143×282
CAM-04 · 14:31:52
CONFIDENCE92%
CLASS
Structural crack
Evidence
4 items
- image
Linear discontinuity through the central boss, 0.4 mm width, high-gradient edge response
- batch
Batch B-2291 defect rate 4.2% vs 2.4% 30-batch baseline (+1.8 pts)
- process
Unit produced 11 min after die changeover; press temp 173 °C (target 182 °C)
- history
9 of last 12 crack detections on Press 02 occurred within 25 min of a changeover
Verdict
Confidence92%
Uncertainty (ensemble spread)6%
Novelty distance12%
Above threshold with low ensemble spread. Disposition: reject / route to rework assessment.
Batch & process context
- Batch
- B-2291
- Station
- Press 02
- Batch defect rate
- 4.2%
- Units in batch
- 1,260
- Cycle at capture
- 43s
- Takt
- 36s
- Process temp
- 173 °C
- Since changeover
- 11 min
- Station utilisation
- 98%
- Shift
- 2
Trace forward
Model outputs are from a demonstration detector on sample data. Verdicts are advisory and require engineer disposition.
